Monel Alloy 400 Weld Elbow
Welcome to Jay Steel, the leading manufacturer of high-quality tube fittings. We are pleased to introduce our Monel Alloy 400 Weld Elbow, an essential component designed for reliable performance in demanding environments. Monel Alloy 400, a nickel-copper alloy, is renowned for its excellent corrosion resistance and high mechanical strength. These properties make our Monel Alloy 400 Weld Elbow the perfect choice for industries requiring robust and durable fittings. At Jay Steel, we ensure each product meets rigorous quality standards, providing you with the assurance of superior performance and longevity.
Our Monel Alloy 400 Weld Elbow is engineered to provide a secure and leak-proof connection, facilitating efficient flow changes in piping systems. Whether your application is in the chemical, marine, or oil and gas industries, Jay Steel’s commitment to precision manufacturing and quality control ensures that our weld elbows perform exceptionally well in the most challenging conditions. Trust Jay Steel for reliable, high-performance tube fittings tailored to meet your specific needs.
P1 Table
| P1 Type | P1 Size | ||
|---|---|---|---|
| ML | Metric Ferrule | 1 | 1/16 |
| FL | Fractional Ferrule | 2 | 1/8 or 2mm |
| MT | Metric Tube | 3 | 3/16 or 3mm |
| FT | Fractional Tube | 4 | 1/4 or 4mm |
| 5 | 5/16 | ||
| 6 | 3/8 or 6mm | ||
| 8 | 1/2 or 8mm | ||
| 10 | 5/8 or 10mm | ||
| 12 | 3/4 or 12mm | ||
| 14 | 7/8 or 14mm | ||
| 15 | 15mm | ||
| 16 | 1 or 16mm | ||
| 18 | 1 1/8 or 18mm | ||
| 20 | 1 1/4 or 20mm | ||
| 22 | 22mm | ||
| 24 | 1 1/2 or 24mm | ||
| 25 | 25mm | ||
| 28 | 28mm | ||
| 30 | 30mm | ||
| 32 | 2 or 32mm | ||
| 38 | 38mm | ||
| 50 | 50mm | ||
P2 Table
P2 Type | P2 Size | ||
|---|---|---|---|
NS | NPT Thread | 5 | M5x0.8 or 5/16-24 or 5/16 |
ONS | O-ring with NPT Thread | 6 | M6x1 or ⅜-24 or 3/8 or 3/8xSCH80 or G3/8 |
RT | ISO Tapered Thread | 7 | 7/16-20 |
RS | ISO Parallel Thread (For RS Gasket) | 8 | M8x1 or 1/2-20 or 1/2 or 1/2xSCH80 or G1/2 |
RP | ISO Parallel Thread (For RP Gasket) | 9 | 9/12-18 |
RG | Female ISO Parallel (For RP Gasket) | 10 | M10 x 1 or 5/8 |
RJ | ISO Parallel Thread (For RJ Gasket) | 12 | M12x1.5 or 3/4-16 or 3/4 or |
BP | Male ISO Parallel Thread (For RG Gasket) | 14 | M14x1.4 or 7/8-14 |
PP | Positionable, ISO Straight Thread | 16 | M16x1.5 or 1 or 1xSCH80 or G1 |
ST | SAE/MS Straight Thread (Light Duty) | 17 | 1 1/16-12 |
SH | SAE/MS Straight Thread (Heavy Duty) | 18 | M18x1.5 |
OST | O-ring with SAE/MS Straight Thread | 19 | 1 5/16-12 |
AN | 37° Flare | 20 | M20x1.5 or 1 1/4 or 1 1/4xSCH80 or G1 1/2 |
MS | Metric Thread (For RG-M Gasket) | 21 | 1 5/8-12 |
MRS | Metric Thread (For RG-M Gasket) | 22 | M22x1.5 |
MST | O-ring with Metric Thread | 24 | M24x1.5 or 1 1/2 or 1 1/2xSCH80 or G1 1/2 |
TS | Fractional Tube Socket Weld | 26 | 1 5/8-12 |
PB | Pipe Butt Weld | 27 | M27x2 |
30 | 1 7/8-12 | ||
Phone
- 1234567895
- demo@gmail.com
Address
- Lorem ipsum dolor sit amet
Benefits:
Choosing Jay Steel’s Monel Alloy 400 Weld Elbow offers numerous advantages:
- Exceptional Corrosion Resistance: Ideal for use in highly corrosive environments such as chemical processing and marine applications.
- High Mechanical Strength: Capable of withstanding high-pressure and high-stress conditions, ensuring secure and reliable connections.
- Versatile Applications: Suitable for a wide range of industrial uses due to its robust design and material properties.
- Leak-Proof Design: Precision engineering ensures a tight and secure fit, preventing leaks and maintaining system integrity.
- Durable and Long-Lasting: Reduces maintenance needs and extends product lifespan, providing cost-efficiency over time.
Grades Available:
Jay Steel offers Monel Alloy 400 Weld Elbows in the following grade specification:
Grade | Material Composition | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
Monel Alloy 400 | 63% Ni, 28-34% Cu, 2.5% Fe, 2% Mn | 550 | 240 | 30 |
Types of the Product:
Our Monel Alloy 400 Weld Elbows are available in various configurations to meet diverse application needs, including:
- 45-Degree Weld Elbow
- 90-Degree Weld Elbow
- Long Radius Weld Elbow
- Short Radius Weld Elbow
Industrial Application:
Jay Steel’s Monel Alloy 400 Weld Elbows are utilized across multiple industries due to their exceptional properties:
- Chemical Processing: Resistant to corrosive chemicals and suitable for harsh processing environments.
- Marine Engineering: Provides durability against seawater and marine atmospheres.
- Oil and Gas: Designed to handle high-pressure and corrosive conditions reliably.
- Power Generation: Ensures reliability in high-temperature and high-stress environments.
Testing:
To guarantee the highest quality and performance, Jay Steel conducts comprehensive testing on all our products. Our testing procedures include:
- Chemical Analysis: Ensuring the material composition meets the specified standards.
- Dimensional Inspection: Verifying precise measurements for a perfect fit.
- Mechanical Testing: Assessing tensile and yield strengths for durability.
- Pressure Testing: Ensuring leak-proof performance under operational conditions.
Why Choose Jay Steel:
Jay Steel is the trusted choice for tube fittings for several compelling reasons:
- Unmatched Quality: We adhere to the highest standards of quality, ensuring each product performs exceptionally.
- Expertise and Innovation: Our extensive experience and technical knowledge enable us to provide innovative solutions tailored to your needs.
- Customer Commitment: We prioritize customer satisfaction by offering superior products and exceptional service.
- Global Reach: With a vast network and international presence, Jay Steel efficiently delivers products and support worldwide.
Choose Jay Steel for your Monel Alloy 400 Weld Elbow needs and experience the superior quality and performance that sets us apart. Contact us today to learn more about our products and how we can support your industrial requirements.
