Monel Alloy 400 Female Elbow

Welcome to Jay Steel, a renowned manufacturer of premium-quality tube fittings. With a legacy of excellence and innovation, Jay Steel stands as a leader in the industry, providing top-notch solutions for various industrial applications. Our Monel Alloy 400 Female Elbows exemplify our commitment to quality, precision, and reliability. Engineered to meet the highest standards, our fittings offer unparalleled performance and durability.

P1 Table

P1 Type		P1 Size
ML	Metric Ferrule	1	1/16
FL	Fractional Ferrule	2	1/8 or 2mm
MT	Metric Tube	3	3/16 or 3mm
FT	Fractional Tube	4	1/4 or 4mm
		5	5/16
		6	3/8 or 6mm
		8	1/2 or 8mm
		10	5/8 or 10mm
		12	3/4 or 12mm
		14	7/8 or 14mm
		15	15mm
		16	1 or 16mm
		18	1 1/8 or 18mm
		20	1 1/4 or 20mm
		22	22mm
		24	1 1/2 or 24mm
		25	25mm
		28	28mm
		30	30mm
		32	2 or 32mm
		38	38mm
		50	50mm

P2 Table

P2 Type		P2 Size
NS	NPT Thread	5	M5x0.8 or 5/16-24 or 5/16
ONS	O-ring with NPT Thread	6	M6x1 or ⅜-24 or 3/8 or 3/8xSCH80 or G3/8
RT	ISO Tapered Thread	7	7/16-20
RS	ISO Parallel Thread (For RS Gasket)	8	M8x1 or 1/2-20 or 1/2 or 1/2xSCH80 or G1/2
RP	ISO Parallel Thread (For RP Gasket)	9	9/12-18
RG	Female ISO Parallel (For RP Gasket)	10	M10 x 1 or 5/8
RJ	ISO Parallel Thread (For RJ Gasket)	12	M12x1.5 or 3/4-16 or 3/4 or
BP	Male ISO Parallel Thread (For RG Gasket)	14	M14x1.4 or 7/8-14
PP	Positionable, ISO Straight Thread	16	M16x1.5 or 1 or 1xSCH80 or G1
ST	SAE/MS Straight Thread (Light Duty)	17	1 1/16-12
SH	SAE/MS Straight Thread (Heavy Duty)	18	M18x1.5
OST	O-ring with SAE/MS Straight Thread	19	1 5/16-12
AN	37° Flare	20	M20x1.5 or 1 1/4 or 1 1/4xSCH80 or G1 1/2
MS	Metric Thread (For RG-M Gasket)	21	1 5/8-12
MRS	Metric Thread (For RG-M Gasket)	22	M22x1.5
MST	O-ring with Metric Thread	24	M24x1.5 or 1 1/2 or 1 1/2xSCH80 or G1 1/2
TS	Fractional Tube Socket Weld	26	1 5/8-12
PB	Pipe Butt Weld	27	M27x2
		30	1 7/8-12

Phone

Email

Address

Benefits:

Choosing Jay Steel’s Monel Alloy 400 Female Elbows offers numerous benefits:

Corrosion Resistance: Made from Monel Alloy 400, our fittings exhibit exceptional resistance to corrosion, ensuring longevity and reliability in corrosive environments.
Versatility: With a female elbow design, our fittings offer versatility in connecting pipes and tubing, allowing for easy installation and configuration.
High Strength: Crafted from high-strength materials, our fittings provide robustness and durability, capable of withstanding high-pressure and high-temperature conditions.
Precision Engineering: Meticulously designed for precise fit and alignment, our female elbows ensure leak-free connections and optimal performance.
Wide Range of Sizes: Available in various sizes and configurations, our fittings cater to diverse piping system requirements, offering flexibility and customization options.

Grades Available:

Jay Steel offers Monel Alloy 400 Female Elbows in the following grade specification:

Grade	Material Composition	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)
Monel Alloy 400	63% Ni, 28-34% Cu, 2.5% Fe, 2% Mn	550	240	30

Types of the Product:

Our Monel Alloy 400 Female Elbows are available in various configurations to suit different applications, including:

90-Degree Female Elbow: Featuring a 90-degree bend, these elbows are suitable for standard piping applications requiring directional changes.
45-Degree Female Elbow: Designed for applications where a sharper bend angle is required, these elbows offer flexibility in tight spaces and complex piping systems.

Industrial Application:

Jay Steel’s Monel Alloy 400 Female Elbows find applications across a wide range of industries, including:

Chemical Processing: Ideal for chemical plants, refineries, and petrochemical facilities, our fittings offer corrosion resistance and reliability in handling corrosive fluids.
Marine Industry: Suitable for shipbuilding, offshore platforms, and marine pipelines, our fittings withstand the harsh conditions of seawater and marine environments.
Oil and Gas Sector: Used in oil rigs, pipelines, and refineries, our fittings provide durability and performance in demanding oil and gas applications.
Power Generation: Employed in power plants for steam and gas systems, our fittings offer high-temperature and pressure resistance for efficient operation.

Testing:

At Jay Steel, we subject all our Monel Alloy 400 Female Elbows to rigorous testing to ensure adherence to quality standards and performance reliability. Our testing procedures include:

Chemical Analysis: Verifying material composition to meet specified standards.
Dimensional Inspection: Ensuring precise measurements and fit for seamless integration into piping systems.
Mechanical Testing: Evaluating tensile strength, yield strength, and elongation properties to ensure mechanical integrity.
Leak Testing: Conducting pressure and leak tests to confirm leak-free performance and integrity of connections.

Why Choose Jay Steel:

Quality Assurance: Jay Steel is committed to delivering tube fittings of the highest quality, meeting stringent industry standards.
Reliability: With a reputation for reliability and durability, our fittings offer long-term performance and peace of mind.
Customization: We offer customization options to meet specific project requirements, ensuring tailored solutions for our clients.
Technical Expertise: Backed by years of experience and technical expertise, our team delivers superior products and exceptional service.
Customer Satisfaction: At Jay Steel, customer satisfaction is our priority, and we strive to exceed expectations through superior products and support.

Choose Jay Steel for your Monel Alloy 400 Female Elbows and experience unmatched quality, reliability, and performance in your piping systems. Trust us to provide fittings that meet your specific needs and deliver exceptional results in all industrial applications.
