Monel Alloy 400 Bulkhead Union

Welcome to Jay Steel, a premier manufacturer of top-notch tube fittings, specializing in the production of Monel Alloy 400 Bulkhead Unions. Monel Alloy 400 is renowned for its exceptional corrosion resistance and impressive mechanical properties, making it an ideal choice for demanding industrial environments. Our bulkhead unions are meticulously engineered to ensure secure, leak-proof connections that perform reliably even under the harshest conditions. At Jay Steel, we leverage advanced manufacturing techniques and rigorous quality control processes to deliver products that meet the highest standards of durability and performance.

P1 Table

P1 Type		P1 Size
ML	Metric Ferrule	1	1/16
FL	Fractional Ferrule	2	1/8 or 2mm
MT	Metric Tube	3	3/16 or 3mm
FT	Fractional Tube	4	1/4 or 4mm
		5	5/16
		6	3/8 or 6mm
		8	1/2 or 8mm
		10	5/8 or 10mm
		12	3/4 or 12mm
		14	7/8 or 14mm
		15	15mm
		16	1 or 16mm
		18	1 1/8 or 18mm
		20	1 1/4 or 20mm
		22	22mm
		24	1 1/2 or 24mm
		25	25mm
		28	28mm
		30	30mm
		32	2 or 32mm
		38	38mm
		50	50mm

P2 Table

P2 Type		P2 Size
NS	NPT Thread	5	M5x0.8 or 5/16-24 or 5/16
ONS	O-ring with NPT Thread	6	M6x1 or ⅜-24 or 3/8 or 3/8xSCH80 or G3/8
RT	ISO Tapered Thread	7	7/16-20
RS	ISO Parallel Thread (For RS Gasket)	8	M8x1 or 1/2-20 or 1/2 or 1/2xSCH80 or G1/2
RP	ISO Parallel Thread (For RP Gasket)	9	9/12-18
RG	Female ISO Parallel (For RP Gasket)	10	M10 x 1 or 5/8
RJ	ISO Parallel Thread (For RJ Gasket)	12	M12x1.5 or 3/4-16 or 3/4 or
BP	Male ISO Parallel Thread (For RG Gasket)	14	M14x1.4 or 7/8-14
PP	Positionable, ISO Straight Thread	16	M16x1.5 or 1 or 1xSCH80 or G1
ST	SAE/MS Straight Thread (Light Duty)	17	1 1/16-12
SH	SAE/MS Straight Thread (Heavy Duty)	18	M18x1.5
OST	O-ring with SAE/MS Straight Thread	19	1 5/16-12
AN	37° Flare	20	M20x1.5 or 1 1/4 or 1 1/4xSCH80 or G1 1/2
MS	Metric Thread (For RG-M Gasket)	21	1 5/8-12
MRS	Metric Thread (For RG-M Gasket)	22	M22x1.5
MST	O-ring with Metric Thread	24	M24x1.5 or 1 1/2 or 1 1/2xSCH80 or G1 1/2
TS	Fractional Tube Socket Weld	26	1 5/8-12
PB	Pipe Butt Weld	27	M27x2
		30	1 7/8-12

Phone

Email

Address

Benefits:

Choosing Jay Steel’s Monel Alloy 400 Bulkhead Unions provides numerous advantages:

Superior Corrosion Resistance: Excellent resistance to a wide range of corrosive environments, including acids, alkalis, and seawater.
High Mechanical Strength: Robust construction capable of withstanding high pressure and stress, ensuring reliable performance.
Thermal Stability: Maintains mechanical integrity across a wide temperature range, providing consistent performance.
Versatile Applications: Suitable for diverse industrial environments, from chemical processing to marine engineering.
Secure Connection: Ensures a reliable, leak-proof connection, essential for high-pressure and high-temperature applications.

Grades Available:

Jay Steel offers Monel Alloy 400 Bulkhead Unions in the following grade specification:

Grade	Material Composition	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)
Monel Alloy 400	63% Ni, 28-34% Cu, 2.5% Fe, 2% Mn	550	240	30

Types of the Product:

Our Monel Alloy 400 Bulkhead Unions are available in various configurations to meet specific application needs:

Standard Bulkhead Union: Designed for general industrial applications requiring secure and reliable connections through bulkheads or panels.
Reducing Bulkhead Union: Connects pipes of different diameters, ensuring seamless flow and reliable performance in diverse applications

Industrial Application:

Jay Steel’s Monel Alloy 400 Bulkhead Unions are utilized across a wide range of industries, including:

Chemical Processing: Ideal for handling corrosive chemicals and aggressive environments, ensuring long-term reliability.
Marine Engineering: Perfect for use in seawater and other marine conditions due to their excellent corrosion resistance.
Oil and Gas: Used in offshore and onshore drilling operations, providing reliable connections under extreme conditions.
Power Generation: Essential for high-temperature and high-pressure applications in power plants.
Pharmaceutical Manufacturing: Ensures sterile and corrosion-free connections in sensitive production environments.

Testing:

To guarantee the highest quality, Jay Steel performs comprehensive testing on all Monel Alloy 400 Bulkhead Unions:

Chemical Analysis: Verifies material composition to ensure adherence to specifications.
Dimensional Inspection: Confirms exact measurements and fit through precise measurements.
Mechanical Testing: Assesses tensile strength, yield strength, and elongation for mechanical reliability.
Thermal Testing: Evaluates performance stability under various temperature conditions.
Corrosion Testing: Conducts extensive tests to ensure resistance to corrosive environments, guaranteeing long-term durability.

Why Choose Jay Steel:

Superior Quality: Jay Steel is committed to producing tube fittings that meet the highest industry standards, ensuring exceptional performance and reliability.
Customized Solutions: We offer tailored solutions designed to meet your specific requirements, providing the perfect fit for your application.
Proven Durability: Our products are built to withstand the most challenging environments, ensuring long-lasting performance.
Global Reach: With a strong global presence, we ensure timely delivery and support to our customers worldwide.
Outstanding Customer Service: At Jay Steel, customer satisfaction is our priority, offering comprehensive service and support from selection to delivery.

Choose Jay Steel for your Monel Alloy 400 Bulkhead Unions and experience the benefits of top-quality products, reliable performance, and exceptional service. Trust us to provide fittings that meet your exact needs and deliver outstanding results in all your industrial applications
