Alloy 20 45 Degree Positionable Male Elbow

Welcome to Jay Steel, the leading manufacturer of high-quality tube fittings. Our Alloy 20 45 Degree Positionable Male Elbow is expertly crafted to provide exceptional performance in a variety of demanding environments. Alloy 20, a nickel-iron-chromium-molybdenum alloy, is renowned for its superior resistance to sulfuric acid and other aggressive chemicals, making it an ideal choice for corrosive settings. At Jay Steel, we are committed to delivering products that meet the highest standards of quality and reliability. Choose Jay Steel for your Alloy 20 45 Degree Positionable Male Elbow needs and experience unmatched durability and performance.

P1 Table

P1 Type		P1 Size
ML	Metric Ferrule	1	1/16
FL	Fractional Ferrule	2	1/8 or 2mm
MT	Metric Tube	3	3/16 or 3mm
FT	Fractional Tube	4	1/4 or 4mm
		5	5/16
		6	3/8 or 6mm
		8	1/2 or 8mm
		10	5/8 or 10mm
		12	3/4 or 12mm
		14	7/8 or 14mm
		15	15mm
		16	1 or 16mm
		18	1 1/8 or 18mm
		20	1 1/4 or 20mm
		22	22mm
		24	1 1/2 or 24mm
		25	25mm
		28	28mm
		30	30mm
		32	2 or 32mm
		38	38mm
		50	50mm

P2 Table

P2 Type		P2 Size
NS	NPT Thread	5	M5x0.8 or 5/16-24 or 5/16
ONS	O-ring with NPT Thread	6	M6x1 or ⅜-24 or 3/8 or 3/8xSCH80 or G3/8
RT	ISO Tapered Thread	7	7/16-20
RS	ISO Parallel Thread (For RS Gasket)	8	M8x1 or 1/2-20 or 1/2 or 1/2xSCH80 or G1/2
RP	ISO Parallel Thread (For RP Gasket)	9	9/12-18
RG	Female ISO Parallel (For RP Gasket)	10	M10 x 1 or 5/8
RJ	ISO Parallel Thread (For RJ Gasket)	12	M12x1.5 or 3/4-16 or 3/4 or
BP	Male ISO Parallel Thread (For RG Gasket)	14	M14x1.4 or 7/8-14
PP	Positionable, ISO Straight Thread	16	M16x1.5 or 1 or 1xSCH80 or G1
ST	SAE/MS Straight Thread (Light Duty)	17	1 1/16-12
SH	SAE/MS Straight Thread (Heavy Duty)	18	M18x1.5
OST	O-ring with SAE/MS Straight Thread	19	1 5/16-12
AN	37° Flare	20	M20x1.5 or 1 1/4 or 1 1/4xSCH80 or G1 1/2
MS	Metric Thread (For RG-M Gasket)	21	1 5/8-12
MRS	Metric Thread (For RG-M Gasket)	22	M22x1.5
MST	O-ring with Metric Thread	24	M24x1.5 or 1 1/2 or 1 1/2xSCH80 or G1 1/2
TS	Fractional Tube Socket Weld	26	1 5/8-12
PB	Pipe Butt Weld	27	M27x2
		30	1 7/8-12

Phone

Email

Address

Benefits:

Choosing Jay Steel’s Alloy 20 45 Degree Positionable Male Elbow fittings offers numerous benefits:

Outstanding Corrosion Resistance: Alloy 20 is highly resistant to sulfuric acid and other harsh chemicals, making it ideal for corrosive environments.
Superior Strength and Durability: These fittings are designed to handle high pressure and temperature conditions, ensuring long-term reliability.
Versatile Applications: Suitable for a wide range of industries including chemical processing, petrochemical, pharmaceuticals, and more.
Ease of Installation: Designed for easy and secure installation, reducing downtime and labor costs.
Consistent Performance: Our rigorous quality control processes ensure reliable and consistent performance, minimizing maintenance needs.

Grades Available:

Jay Steel offers Alloy 20 45 Degree Positionable Male Elbow fittings in various grades to meet specific industrial requirements. Below are the specifications for each grade:

Grade	Material Composition	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)
Alloy 20	32-38% Ni, 19-21% Cr, 2-3% Mo, 3.5-4.5% Cu	620	300	30

Types of the Product:

Jay Steel provides a variety of Alloy 20 45 Degree Positionable Male Elbow fittings to cater to different application needs:

Standard 45 Degree Positionable Male Elbow: Ideal for general industrial applications requiring reliable angular connections.
High-Pressure 45 Degree Positionable Male Elbow: Designed to withstand high-pressure environments, ensuring safety and durability.
Compact 45 Degree Positionable Male Elbow: Perfect for use in space-constrained applications, offering robust performance in a smaller form factor.
High-Temperature 45 Degree Positionable Male Elbow: Engineered to maintain integrity and performance in high-temperature conditions.

Industrial Application:

Alloy 20 45 Degree Positionable Male Elbow fittings from Jay Steel are utilized in a range of industries, including:

Chemical Processing: Reliable connections for systems handling corrosive chemicals and aggressive substances.
Petrochemical: Durable fittings for pipelines and processing facilities.
Pharmaceuticals: Ensuring hygienic and secure connections in controlled environments.
Food and Beverage: Safe and efficient fittings for food processing and handling systems.
Water Treatment: Corrosion-resistant fittings for water and wastewater treatment systems.

Testing:

Jay Steel ensures the quality and performance of our Alloy 20 45 Degree Positionable Male Elbow fittings through comprehensive testing procedures:

Material Testing: Verification of high-grade Alloy 20 to meet industry standards.
Dimensional Inspection: Ensuring precise dimensions for accurate fittings.
Pressure Testing: Confirming performance under various pressure conditions.
Corrosion Testing: Assessing resistance to corrosion to guarantee long-term durability.

Why Choose Jay Steel:

Uncompromising Quality: We adhere to stringent quality standards to ensure our products meet and exceed customer expectations.
Industry Expertise: With extensive experience in the industry, we provide innovative solutions tailored to your specific needs.
Customer-Focused Service: We prioritize customer satisfaction, offering personalized support and services.
Global Reach: As a leading manufacturer, we have a robust supply chain, ensuring timely delivery and consistent product quality.
Competitive Pricing: We offer high-quality products at competitive prices, ensuring excellent value for your investment.

Choose Jay Steel for your Alloy 20 45 Degree Positionable Male Elbow fittings and experience unparalleled quality, reliability, and service. Trust us to provide fittings that meet the highest standards of performance and durability, enhancing the efficiency and safety of your industrial operations.
